Long Working Distance XDY-1 Inverted And Reflected Fluorescence Microscope
Brief Introduction:
Iqualitrol XDY-1 Inverted & Reflected Fluorescence Microscopes is composed with inverted microscope and reflected fluorescence microscope, equipped with long working distances plan achromatic objectives and wide field eyepieces.
You can use long working distance phase contrast objectives and special long working distance condenser with phase contrast unit when inverted observation, and change the fluorescence excitation system freely.
Iqualitrol XDY-1 microscope has clear image, wide field, compact framework, beautiful sculpt and comfortable operation etc. It's mainly applied to observe the living cell and tissue, liquid and deposits etc, also to observe transparent living without staining and fluorescence slice up, it is the ideal instrument for researching in biology, cells cytology, oncology, genetics, immunology etc.
The microscope can be used for scientific researching, medical treatment, epidemic prevention and animal husbandry etc.
Technical Specifications:
| Model | XDY-1 |
| Eyepiece | Wide field eyepiece WF10X(¦µ20mm) |
| Objective |
Long working distance plan achromatic objectives PL L 10X/0.25 |
|
Long working distance plan achromatic objectives PL L 25X/0.40 |
|
|
Long working distance plan achromatic objectives PL L 40X/0.60 |
|
| Long working distance plan achromatic phase contrast objective PL L 10X/0.25 PHP2 | |
| Long working distance plan achromatic phase contrast objective PL L 25X/0.40 PHP2 | |
| Long working distance plan achromatic phase contrast objective PL L 40X/0.60 PHP2 | |
| Eyepiece tube | Trinocular (Inclination of 30°, 100% image light for photography capable) |
| Focus system | Coaxial coarse/fine focus system, with tensional adjustable and up stop, minimum division of fine focusing: 2μm |
| Nosepiece | Quintuple (Ball bearing inner locating) |
| Stage |
Double layer mechanical (Size: 224mmX208mm, moving range: 112mmX79mm) |
| Filter | Green filter |
| Blue filter | |
| Shelf of specimen | Match to install ¦µ68mm or 77mmX29mm culture utensil |
| Match to install 82mmX57mm culture utensil | |
| Match to install 128mmX85mm 96 holes culture utensil | |
| Reflected fluorescence system | Mercury lamp house 100W/DC |
| Power supply unit:AV:110V or 220V | |
| Fluorescence filter system B exciton wavelength:450~490nm | |
| Fluorescence filter system G exciton wavelength:495~555nm | |
| Fluorescence filter system UV exciton wavelength:320~380nm | |
| Fluorescence filter system V exciton wavelength:380~415nm | |
| Turnplate phase contrast unit | Centering telescope |
| Condenser Rack & pinion adjustable, NA=0.4,working distance: 50mm |
