Touch Screen Digital Low Load Brinell Hardness Tester HBS-62.5AT With Curve Display

Touch Screen Digital Low Load Brinell Hardness Tester IQUALITROL HBS-62.5AT with Hardness Curve Display

Technical Specifications:

Brief Introduction:

HBS-62.5AT digital display automatic turret small load Brinell hardness tester, adopts 8-inch touch screen and high-speed ARM processor, intuitive display, friendly human-computer interaction, easy operation; fast calculation speed, huge database storage, automatic data correction, And provide data line report;

The fuselage is made of high-quality cast iron for one-time casting, combined with the car paint treatment process, the shape is round and beautiful;

HBS-62.5AT is equipped with an automatic turret function, which can automatically switch between the indenter and the lens, making it more convenient to use;

Convenient control system, which can automatically convert the unit of the full hardness scale;

The electronic closed-loop control applies the test force, which fully realizes the automatic operation of loading, holding and unloading of the test force;

The maximum and minimum values of the hardness value can be set, and when the test value exceeds the set range, an alarm will sound;

With software hardness value correction function, the hardness value can be directly corrected within a certain range;

With database function, the test data can be automatically grouped and saved, each group can save 10 data, and can save more than 2000 data;

With hardness value curve display function, visually display the change of hardness value;

Configure a wireless bluetooth printer, and output data through RS232 and USB interfaces;

Optional CCD image processing system or video measuring device;

The precision complies with GB/T231.2-2018, ISO6506-2 and American ASTM E10 standards.
